KEY FEATURES

• Retro 6061 aluminum Big Ripper frame with floval tubing, looptail rear end, American bottom bracket and classic PK Ripper wishbone plate
• Full Cr-Mo Landing Gear forks
• Cr-Mo Big Honkin’ cruiser bars
• Double-wall rims with sealed-bearing and high-flange hubs
• SE 3-piece V-Ridge cranks with alloy SE sprocket
• Authentic ODI Mushroom II grips with donuts
• New SE Bozack 29" x 2.4" tires
• SE Flyer seat with SE bottle opener
• SE Racing padset
• SE Wheelie pegs
• 32 pounds

SPECIFICATIONS

• COLOR(S): Ball Burnished Silver, Purple Rain, Classic Black
• FRAME: 6061 Aluminum Floval Tubing, Looptail Rear End, 68mm American Bottom Bracket, Wide Rear Stays, Retro Dropouts
• FORK: Landing Gear, Full Cr-Mo
• CRANKSET: SE V-Ridge 3-pc Cr-Mo Cranks, 175mm, Sealed American Bottom Bracket, 160mm Spindle Length, 19mm Spindle Diameter, 36T Alloy SE Racing Sprocket
• PEDALS: X-Pedo Low-profile Platform w/ Removable Pins
• CHAIN: KMC S1
• WHEELSET: Sealed Bearing 36H High-Flange Alloy Flip Flop Hubs w/ Double-wall Rims, 16T Freewheel, Stainless Spokes
• TIRES: SE Bozack, Street Proven Multi Purpose Compound, Wrap Around Urban Tread Pattern, Grooved SE Wing Logo, 29" x 2.4" Front & Rear
• BRAKESET: Tektro 855ALV-Brake, Slick Cable
• BRAKE LEVERS: Tektro 316A, 2-Finger Alloy
• HEADSET: Tange 1-1/8" Threadless
• HANDLEBAR: Big Honkin' Cr-Mo Cruiser Bar, 29" x 7", 12° Backsweep, 2° Upsweep
• STEM: Retro Alloy Top-Load w/ Engraved SE Logo on Top & Sides, 55mm Reach
• GRIPS: Special Edition ODI Mushroom II Dual-Ply Grips, Made in USA, w/ SE Donuts
• SEAT: SE Flyer Seat w/ Custom SE Bottle Opener Brace
• SEATPOST: Micro-Adjust Alloy, 27.2mm
• SEAT CLAMP: SE Racing Champ Clamp, Alloy, 31.8mm Inner Diameter
• ACCESSORIES: Classic SE Racing Snap Padset, Alloy Valve Caps, SE Wheelie Pegs
• WEIGHT: 32 lbs / 14.51 kgs

GEOMETRY

• TOP TUBE, ACTUAL: 23.6"
• SEAT TUBE, CENTER TO TOP: 16.9"
• SEAT TUBE ANGLE: 71°
• HEAD TUBE ANGLE: 71°
• CHAINSTAY LENGTH: 18.25"
• WHEELBASE: 44"
• BOTTOM BRACKET HEIGHT: 12.25"
• STANDOVER: 30.75"
• SUGGESTED RIDER SIZE: 5'5"+ (165cm+)
• STEM: 55mm
• HANDLEBAR WIDTH: 29"
• CRANK: 175mm
• WHEEL SIZE: 29"
